PCB Supplier
There is no single PCB fabricate house can meet all the requirements from every customer, that is why we have certified and established close partnership with more than dozen different types of PCB fabricate houses based on the different requirements of our customers, such as urgency of time, design complexity, volume and cost, etc. We will propose the best matching PCB fabricate house from local or overseas as appropriate:
- Quick Turn Project– from local vendors capable of providing quick turn board fabricated, the quickest is within one day
- Complex PCB Project –from PCB fabricate house can do higher-layer count PCBs and more complex assemblies
- Price Sensitive Project – from price competitive fabricate house
- Well Scheduled Project – for project with sufficient lead time, low cost PCB from overseas is available for all types of PCB requirements
Capabilities
| Item | Technical Data |
|---|---|
Types of Products | FR4 Multilayer PCB, Aluminum PCB, Flexible PCB, Special Material PCB, Buried/Blind Via PCB, High Frequency PCB. |
Layers | 1－18 (layers) |
Max. Board Size | 450x660mm 18″ x 26″ |
Max. Board Thickness | 3.2mm |
Min. Board Thickness | 4 (layers) 0.40mm 16mil |
Copper Clad(Max.) | 8 Oz (outer)/4 Oz (inner) |
Min. line Width/space | 0.075mm/0.075mm 3mil/3mil |
Drill Size Mechanical (min.) | 0.15mm 6mil |
Drill Size Laser(min.) | 0.10mm 4mil |
PTH Wall Thickness | 0.025mm 1mil |
PTH via tolerance | ±0.075mm ±3mil |
NPTH hole via tolerance | ±0.05mm ±2mil |
Hole Position Deviation | ±0.05mm ±2mil |
Insulation Resistance | 1E+12Ω(Normal) |
Test Voltage | 50~300V |
Aspect ratio | 12:1 |
Thermal Shock | 3x10Sec@288 ℃ |
Warp and Twist | ≤0.7% |
Current breakdown | 10A |
Electric Strength | ＞1.3KV/mm |
Peel Strength | 1.4N/mm |
Solder Mask Abrasion | ≥6H |
Solder Mask Color | Green, White, Yellow, Red, Black, Blue. |
Silkscreen Color | White, Yellow, Black |
Flammability | 94V-0 |
Impedance Control | +/-10%(＞50Ohm) +/-5% (≤50Ohm) |
Buried Via | Yes |
Blind Via | Yes |
HDI | 2+N+2 4mil Via hole |
Surface Finished | ENIG, IMS, ImSn, OSP, HASL-LF, Carbon ink |
Materials | FR4, Aluminum, Polymide, Rogers etc. |
| Multi-layer FR4 PCB | Heavy copper PCB | Flexible PCB | Aluminum PCB | High TG PCB | Other |
 |  |  |  |  |  |
