P&C’s Manufacturer Management System is an all-in-one platform designed to streamline production control, inventory tracking, quality assurance, and workforce management. Built for scalability and customization, this system empowers manufacturers to maintain high efficiency while adapting to dynamic production requirements.
To serve the production process well, we have created a production management system based on QR code technology. We’ve packaged the system and made it completely applicable to your production application.
In each PCB project, each board will be identified with a unique QRCODE code
QR code scanners are mounted in all locations to monitor every step of PCB production, from SMT to product release (see below…).
USB wired barcode scanner to capture 1D, 2D code on labels, paper, mobile phone or computer.
High-efficiency recognization and high upload speed for improving your working efficiency.
With buzzer for reminding you that the scanning successfully or not.
Compatible with USB and CANinterface.
Over 180 configurable options
Macro support replace a string in the bar code with another
Programmable preamble postamble and termination strings
Superior reading performance utilizing advanced decoding algorithms
Decoding Ability
1D: EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codebar,industrial 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI,postal code ect.
2D: PDF417,QR Code,Data Matrix ect
Resolution: 0.10mm (4mil)
Reading Distance: 25 – 250mm
Interfaces: USB2.0 \ CAN
Type of Illuminant: 617nm LED(Aimer), 6500K LEDs(Illumination)
Scan Angle: Roll:0-360°, Pitch:±65°or greater, Yaw:±60°or greater
Scanning angle Inclination angle: 34°, Elevation angle 26° Print Contrast 30% minimum reflective difference
LED Indicator:Buzzer and bi-color light: Red=power, Blue=decoding Successfully
Operating Temperature:-20 degrees to 55 degrees
Storage Temperature:-40 degrees to 65 degrees
Temperature Humidity:5% to 95% Relative humidity, Non-condensing
Light Levels:0-85000LUX
Operating Current:120mA
Operating Voltage:5-12V
